Maximum sheet size 3050 x 1525 mm
X-axis travel 3080 mm
Y-axis travel 1555 mm
Z-axis travel 100 mm
Maximum sheet weight on table 900 kg
Table changeover time 30 sec.
Maximum positioning speed X-Y 170 m/min.
Repetitive accuracy ± 0.025 mm
Positioning accuracy* ± 0.050 mm

Maximum cutting performance 8 kW
Mild steel 25 mm
Stainless steel 25 mm
Aluminium 30 mm
Copper 12 mm
Brass 10 mm
